Description

Introduction

Our Jumbo Roll Slitting Machine boasts a round knife device that can efficiently cut the web paper into 350g/min. The machine is also equipped with an independent main control screen that adds more flexibility and ease to the operation. Our product is both cost-effective and high-quality, and it is no wonder why our customers love it so much.

Feature

Our state-of-the-art Jumbo Roll Slitting Machine is fully computer controlled with a photoelectric tracking correction system. Our machine's unwinding tension is expertly controlled by a magnetic powder brake and an automatic tension control system. What's more, our innovative rewinding shaft features an inflatable shaft with automatic pressure that rises and falls as needed. The inverter provides complete control over the machine's speed and is equipped with an automatic billing device. Our machine's precise cutting capabilities result in smooth, clean edges and neat winding every time. This makes the subsequent processing of materials easy, efficient, and hassle-free. Trust our Jumbo Roll Slitting Machine to take your production to the next level.

Working width : 2500 mm
Diameter of unwinding : 1500 mm
Brake Type : Pneumatic
Operating speed : 600 m/min
Slitting unit : knife roll with 4 knives
Trim cutting : exhausting fan with suction piping
Diameter of winding : 1500 mm
Cores diameter : 76 mm
Electric drive : power and control electric part

Technique Parameters:

Original paper width：	Max 2000mm， Min 1500mm
Net paper width：	2000mm
Original paper roll diameter：	Φ2500mm
Rewinding paper roll diameter：	≤Φ1500mm
Original paper inner core：	According customer
Rewinding paper inner core：	Φ76.2mm（3''）
